Model No: DLD-SMF
Premium 60W/100W/300W Modular Street Lights | Weatherproof | Customizable
Modular street light Descriptions:
-Die cast aluminum & Aluminum profile
-Driver Brands : Philips/ Invertronics/ Moso/ Meanwell
-Leds: Osram/ Lumileds/ Sanan/ Bridegelux/ Epistar
-AC85-265V/50-60Hz
-3000K/4500K/6500K
-Mounting Diameter: 60mm
-CRI>70/80
-3/5 Years Warranty
-IP65
-Die cast aluminum & Aluminum profile
-Driver Brands : Philips/ Invertronics/ Moso/ Meanwell
-Leds: Osram/ Lumileds/ Sanan/ Bridegelux/ Epistar
-AC85-265V/50-60Hz
-3000K/4500K/6500K
-Mounting Diameter: 60mm
-CRI>70/80
-3/5 Years Warranty
-IP65
Quantity :
0.00
Product Parameters
| Product Name | High-Performance Modular LED Street Lights - Flexible & Professional Road Lighting Solutions | |||||
| Item No. | DLD-SMF-50W | DLD-SMF-100W | DLD-SMF-150W | DLD-SMF-200W | DLD-SMF-250W | DLD-SMF-300W |
| Input Watt | 50W | 100W | 150W | 200W | 250W | 300W |
| LEDs | 3030/50PCS | 3030/100PCS | 3030/ 150PCS | 3030/ 200PCS | 3030/ 250PCS | 3030/ 300PCS |
| Dimensions(mm) | 425*350*90 | 508*350*90 | 591*350*90 | 674*350*90 | 757*350*90 | 840*350*90 |
| Efficiency | >120lm/w | >120lm/w | >120lm/w | >120lm/w | >120lm/w | >120lm/w |
| Input Voltage | AC85-277V/50-60HZ | |||||
| LED brand | Osram/ Lumileds/ Sanan/ Bridegelux/ Epistar | |||||
| Driver Brand | Philips/ Invertronics/ Moso/ Meanwell | |||||
| IK Level | IK08 | |||||
| Power Factor | >0.95 | |||||
| Color Temperature | 3000K/4500K/6500K | |||||
| Material | Aluminum & Optical lens | |||||
| IP Grade | IP65 | |||||
| Warranty | 2 Years | |||||
LED Street Lights Description
Our Modular Street Light series offers six wattage options ranging from 60-watt street lights (60 watt street light) to 100W, 150W, 200W, 250W, and high-power 300W LED street lights (300w led street light), designed to meet diverse illumination requirements from residential roads to highways.
Key Advantages
- Exceptional Durability - Constructed with premium aviation-grade aluminum alloy, featuring spray coating and anodized surface treatment for superior corrosion resistance in harsh outdoor environments.
- High Luminous Efficiency - Delivers up to 120lm/W output, providing bright and uniform lighting while significantly reducing energy consumption.
- Comprehensive Protection - Equipped with surge protection (4KV/10KV/20KV optional) to withstand lightning strikes and voltage fluctuations, extending product lifespan.
- Wide Voltage Compatibility - Supports AC85-265V input, adaptable to various grid conditions globally.
- Tool-Free Maintenance - Hassle-free design minimizes post-installation servicing costs.
Customization Services
• LED Chip Options: Lumileds, Osram, Epistar, and other top-tier international brands available
• Driver Options: High-reliability drivers from Philips, Meanwell, Inventronics, etc.
• 5-Year Extended Warranty - Industry-leading warranty coverage for guaranteed performance
Ideal Applications
Perfect for urban arterial roads, expressways, residential streets, parks, plazas, villa districts, and other outdoor lighting projects requiring high reliability and long service life.
